Adventure Van Systems

LEVEL 2.01 System Wiring Diagram and Parts List

LEVEL 2.01 System Wiring Diagram and Parts List

Regular price $8.00 USD
Regular price $9.00 USD Sale price $8.00 USD
Sale Sold out

System wiring diagram complete with wire sizes and parts list.


The perfect kit for the crew who wants to spend a few days off grid mountain biking or skiing where primary cooking and water heating is done with propane or butane.   Enough 120v AC power to cover the basics.  Complete from batteries to fuse block.


The AVS LEVEL 2.01 system is based on a 200 Ah heated lithium battery bank
and a Victron MultiPlus 12/2000 / 80-50 120v Inverter/Charger.  The system includes solar and alternator charging components, as well as full system monitoring.  More Info


The diagram is currently undergoing final review.  Contact AVS if you need this diagram and we will push it to the front of the line.
